The ROS2 Navigation Stack (Nav2)
The , commonly known as , is the next-gen upgrade to the original ROS Navigation Stack. It's a rock-solid, industry-proven framework that gets autonomous mobile robots from Point A to Point B safely. Nav2 juggles path planning, perception, control, and recovery behaviors, tapping into ROS 2's real-time strengths and smarter architecture.
How It Works
While the old ROS navigation stack was just a basic finite state machine, Nav2 brings a super modular, extensible setup powered by . This makes tricky navigation logic way easier to debug and tweak. It flows through a pipeline of connected nodes:
1. The Navigation Behavior Tree
At Nav2's core sits the Behavior Tree (BT) Navigator. Forget linear logic—BTs build a hierarchy of tasks. It figures out to plan a path, to follow it, and to kick off recovery moves (like backing up or spinning) if the robot gets stuck. This keeps decisions dynamic and super responsive.
2. Global and Local Planners
Navigation is split into two distinct planning phases:
- Global Planner:
- Local Planner (Controller):
3. Costmaps
Nav2 tracks two "costmaps" (2D grids marking obstacle risks in each cell):
- Global Costmap:
- Local Costmap:
4. Lifecycle Managed Nodes
A standout in ROS 2 is Lifecycle Nodes. Nav2 fires up all servers (planners, controllers, map servers) in a precise sequence (Unconfigured → Inactive → Active). No more chaotic starts where robots try moving before sensors or maps are ready.
Applications in Robotics
Nav2's modularity makes it the go-to for tons of autonomous machines:
- Intralogistics & Warehousing:
- Service Robotics:
- Agriculture:
- Security and Patrol:
